Technical Specifications
General
Number of Ports
• DGS-1016D: Sixteen 10/100/1000 Gigabit ports
• DGS-1024D: Twenty-four 10/100/1000 Gigabit ports
Standards
• IEEE 802.3 10BASE-T Ethernet
• IEEE 802.3u 100BASE-TX Fast Ethernet
• IEEE 802.3ab 1000BASE-T Gigabit Ethernet
• ANSI/IEEE 802.3 NWay auto-negotiation
• IEEE 802.3x Flow Control
Data Transfer Rates
• Ethernet:
• 10 Mbps (half duplex)
• 20 Mbps (full duplex)
• Fast Ethernet:
• 100 Mbps (half duplex)
• 200 Mbps (full duplex)
• Gigabit Ethernet:
• 2000 Mbps (full duplex)
Network Cables
• 10BASE-T:
• UTP CAT 3, 4, 5/5e (100 m max)
• EIA/TIA-586 100-ohm STP (100 m max)
• 100BASE-TX, 1000BASE-T:
• UTP CAT 5/5e (100 m max)
• EIA/TIA-568 100-ohm STP (100 m max)
Functionality
D-Link Green Features
• IEEE 802.3az Energy Efficient Ethernet (EEE)
• Link status detection power saving
• Cable length detection power saving
• RoHS Compliance
Media Interface Exchange
• Auto MDI/MDIX
Transmission Method
• Store-and-Forward switching method
MAC Address Table
• 8K MAC addresses
RAM Buffer
• 512 KBytes RAM for data buffering
Jumbo Frames
• DGS-1016D: 9216 Bytes
• DGS-1024D: 9600 Bytes
Switching Capacity
• DGS-1016D: 32 Gbps
• DGS-1024D: 48 Gbps
Port Packet Filtering
• 10M: 14,880 pps
• 100M: 148,800 pps
• 1000M: 1,488,000 pps
LEDs
• DGS-1016D:
• Power LED
• 16 Link/Activity/Speed LEDs (one per port)
• DGS-1024D:
• Power LED
• 24 Link/Activity/Speed LEDs (one per port)
Power Inputs
• 100 to 240V AC Input
Power Consumption
• DGS-1016D:
• Standby: 4.48 watts
• Maximum: 9.84 watts
• DGS-1024D:
• Standby: 6.5 watts
• Maximum: 13.5 watts
Heat Dissipation
• DGS-1016D:
• Standby: 15.2768 btU/h
• Maximum: 33.5544 btU/h
• DGS-1024D:
• Standby: 22.165 btU/h
• Maximum: 44.035 btU/h
MTBF
• DGS-1016D: 795,539 hours
• DGS-1024D: 633,536 hours
Dimensions
• DGS-1016D: 11.02 x 4.92 x 1.73 inches (280 x 125 x 44 mm)
• DGS-1024D: 11.02 x 7.09 x 1.73 inches (280 x 180 x 44 mm)
Weight
• DGS-1016D: 2.34 lbs (1.06 kg)
• DGS-1024D: 3.66 lbs (1.66 kg)
Operating Temperature
• 32 to 104 °F (0 to 40 °C)
Storage Temperature
• 14 to 158 °F (-10 to 70 °C)
Humidity
• 5% to 90% non-condensing
Certifications
• FCC Class A
• ICES-003 Class A
• CE Class A
• C-Tick Class A
• CB
• cUL
Ordering Information
• DGS-1016D 16-Port Gigabit Unmanaged Desktop or Rackmount Switch
• DGS-1024D 24-Port Gigabit Unmanaged Desktop or Rackmount Switch
